GG-IPSH01-30M

Model ：

GG-IPSH01-30M

Introduction

Specification

l PoE eliminates need for local power supply;

l 2-Way Intercom Communication;

l 48K OPUS Audio Codec, AEC, AGC, ANR;

l Compatible with VoIP, SIP devices (IPPBX, IP Phone) via SIP;

l Compatible with IP Camera VMS via ONVIF;

l Support web firmware upgrade for easy maintenance;

l Support Pre-recorded messages;

l Support HTTP API for alarm in transmit.

l Built-in TF Card Slot;

peaker
Max SPL	120dB
Frequency Response	350Hz ~ 8KHz
Frequency Range	500-2KHZ +-10dB 400-12KHZ +-20dB
Harmonic Distortion	0.1@1kHz
Signal to Noise Ratio	91dB
Audio
Codec	OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711,PCMA 8 kHz
Network
Security	Password protection, IP address filtering, Digest authentication, User access log, firewall
Network Protocol	SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP
Network Interface	10/100 Base-TX, RJ45
VoIP	Support for SIP protocol for intergration with VoIP systems, intergrated with SIP/PBX. 2 SIP Accounts, SIP Direct IP Call, RTP Multicast Codec: OPUS, MP3, G.722, PCMU, PCMA
Amplifier
Description	Built-in 30W Amplifier
MIC
Built-in MIC	YES
Interface	GPIO Alarm in, Audio in, TF Card Slot
General
Operation Temp and Humidity	-30 to 60 degree, 5% to 85%
Material	ABS IP67 Rated
Rate Power	30W
Power Supply	PoE or DC 12V/24V
Dimension	285x 205 x 290 mm
Net Weight	2KG
Languages	English
