DD2 Middle Box

Introduction

Specification

① 240W PCM and MeanWell UL DC48V/5A Din Rail Power Supply with Battery Management;

② Air Breaker/Surge Protector/ Temp Controller and 2 UL Fans for Cooling;

③ 70CM AC Wire with IP68 Water-Proof Stainless Connector,and AC Wire Water-Proof UL Male&Female Connector;

④ NPT 3/4" Knockout with Cap;

⑤ With 4G Antennas Installation;

⑥ With Horn Speaker Installation and Cable-In Design;

⑦ Stainless Hand-Carrier;

⑧ With Pole&Wall Mount(Fast Installation Design);

⑨ With 8CH 1000M Industrial PoE+ Switch;

⑩ With Sound AI PoE Light Siren.

Sound AI PoE Light Siren(Blue/Red/White Version)
Network Part
Protocols	MQTT, Onvif, TCP/IP, UDP, IPV4/V6, HTTP, HTTPS, DHCP, DNS, ICMP,SMTP,
Ethernet	RJ-45 (10/100 Base-T)
Device Interface
POE	PoE In
Alarm	Alarm In and Alarm Out
Speaker(Audio)	Yes,4Ω3W
MIC	Yes(Upto 8 Meters Detection Distance)
Deterrence Light	White/Red/Green(Light Intensity Adjustable by Web ) White: 12W Max Blue:3W Max Red:1.5W Max
Sound AI
Keyword Detection(HELP ME, HELP 911, EMERGENCY), Noise, Scream Detection, Glass Break and Gunshot
General Information
Power Supply	PoE/DC12V, 25W Max
Dimension	205mm x 50mm x 27mm(Thickness)
Weight	420g
Mounting	Wall and Ceiling
Water-Proof	IP67 Rated
Housing Material	Full Aluminum(CNC)
Working Temp.	-20 to 50 degree
240W Power Control Module
Power Inputs	DC40-57V/5A and DC8-36V/20A Max Dual Inputs(300W Max Load)
Power Outputs	DC48V/3A, DC24V/3A, DC12V/3A 7CH, and Channel 7 is Controlled by Alarm Input Channel.
Alarm In&Out	Input 1CH
Box General Information
Material	Aluminum Box Body, Metal Pole&Wall Mount
Weight	18.45KG(Including Package Box and Inside Components)
Dimension	19.68”H x 17.32”W x 8.53”D(Not Include Mount Plate Depth)
Back-up Battery
Battery Choice	48V/3Ah or 38Ah, with Heater(Battery Ship Separately as Default)
Battery Types	Ternary Lithium
